What is Recycle Energy?

"Recycled Energy" is a term developed by the founder of the Renewable Energy Institute (REI).  Recycled energy deals with the recovery of wasted energy, including "wasted heat." REI's founder spent most of the period between 1985 through 1995 advocating, selling or marketing natural gas with two large utilities, and led development of several; cogeneration and trigeneration power plants as well as other demand side management solutions for his large commercial and industrial clients that included direct-fired absorption chillers and engine driven chillers.

The market potential for recycled energy is significant.  Increased use of recycled energy technologies decreases dependence on foreign oil and also greenhouse gas emissions.


CHP Systems
  *  EcoGeneration  *  Energy Master Planning  *  Net Zero Energy

Solar Cogeneration  *  Solar Trigeneration  *  Trigeneration  *  Waste Heat Recovery


Recycled Energy

Absorption Chillers  *  CHP Systems   *   NetZero Energy  *  Trigeneration  *  Waste Heat Recovery



inquiries@RecycledEnergy.com















Clean Power Generation Solutions


CHP Systems (Cogeneration and Trigeneration) Plants
Have Very  High Efficiencies, Low Fuel Costs & Low Emissions

The Effective Heat Rate is Approximately
4100 btu/kW & System Efficiency is 92% Plant.

The CHP System below is Rated at 900 kW and Features:
(2) Natural Gas Engines @ 450 kW each on one Skid with Optional
Selective Catalytic Reduction
system that removes Nitrogen Oxides to "non-detect."



CHP Systems may be the best solution for your company's economic and environmental sustainability as we "upgrade" natural gas to clean power with our clean power generation solutions.

Emissions Abatement solutions reduce Nitrogen Oxides to "non-detect" which means our Trigeneration energy systems can be installed and operated in most EPA non-attainment regions!

For qualified clients we will design, build, finance, own, operate and maintain a new:

Clean Power Generation

Cogeneration

Organic Rankine Cycle

Trigeneration

Waste Heat Recovery

energy system, through a Power Purchase Agreement that guarantees
a minimum 10% reduction in our client's energy expenses.

(NOTE: Engineering and related interim project development expenses may be at client's expense but will be
refunded at the close of Power Purchase Agreement or other project financing. Some of our engineering
and EPC services may be provided by one of our Top-ranked ENR Engineering/EPC partner companies.)


To receive a preliminary no-obligation review of your energy, engineering or project plans,
send an introductory email to us at the following email address:


marketing@CHPsystems.com



Recycled Energy
www.RecycledEnergy.com

Anaerobic Digesters  Battery Energy Storage  *  Biomass Gasification  *  Biomethane  *  Clean Power Generation

Cogeneration  Demand Side Management  *  EcoGeneration  *  Emissions Abatement  *  Net Zero Energy

Solar Cogeneration  *  Synthesis Gas  *  Trigeneration  *  Waste Heat Recovery  Waste to Fuel



Recycled Energy information continued

We provide "Recycled Energy" engineering, design and turn-key solutions for customers wanting to decrease their expenses and environmental liability as well as increase their profits.

Some of our "Recycled Energy" products and services include; Waste Heat Recovery, Biomethane (or Renewable Natural Gas) production, Waste to Energy, Waste to Watts, and Waste to Fuel solutions – and may provide a return on investment in less than 12 months. We also offer other energy-saving technologies that may include one or more of the following; absorption chillers, cogeneration, trigeneration Demand Side Management or other Energy Conservation Measures.

Unlike most companies, we are equipment supplier/vendor neutral. This means we help our clients select the best equipment for their specific application. This approach provides our customers with superior performance, decreased operating expenses and increased return on investment.

Waste Heat Recovery and "Recycled Energy"

Many industrial processes generate large amounts of waste energy that simply pass out of plant stacks and into the atmosphere or are otherwise lost. Most industrial waste heat streams are liquid, gaseous, or a combination of the two and have temperatures from slightly above ambient to over 2000 degrees F. Stack exhaust losses are inherent in all fuel-fired processes and increase with the exhaust temperature and the amount of excess air the exhaust contains. At stack gas temperatures greater than 1000 degrees F, the heat going up the stack is likely to be the single biggest loss in the process. Above 1800 degrees F, stack losses will consume at least half of the total fuel input to the process. Yet, the energy that is recovered from waste heat streams could displace part or all of the energy input needs for a unit operation within a plant. Therefore, waste heat recovery offers a great opportunity to productively use this energy, reducing overall plant energy consumption and greenhouse gas emissions.

Waste heat recovery, also known as Recycled Energy, methods used with industrial process heating operations intercept the waste gases before they leave the process, extract some of the heat they contain, and recycle that heat back to the process.

Common methods of recovering heat include direct heat recovery to the process, recuperators/regenerators, and waste heat boilers. Unfortunately, the economic benefits of waste heat recovery do not justify the cost of these systems in every application. For example, heat recovery from lower temperature waste streams (e.g., hot water or low-temperature flue gas) is thermodynamically limited. Equipment fouling, occurring during the handling of “dirty” waste streams, is another barrier to more widespread use of heat recovery systems. Innovative, affordable waste heat recovery methods that are ultra-efficient, are applicable to low-temperature streams, or are suitable for use with corrosive or “dirty” wastes could expand the number of viable applications of waste heat recovery, as well as improve the performance of existing applications.



Recycled Energy via Waste Heat Recovery



Various Methods for Recycled Energy and Waste Heat Recovery

Low-Temperature Waste Heat Recovery Methods – A large amount of energy in the form of medium- to low-temperature gases or low-temperature liquids (less than about 250 degrees F) is released from process heating equipment, and much of this energy is wasted.

Conversion of Low Temperature Exhaust Waste Heat – making efficient use of the low temperature waste heat generated by prime movers such as micro-turbines, IC engines, fuel cells and other electricity producing technologies. The energy content of the waste heat must be high enough to be able to operate equipment found in cogeneration and trigeneration power and energy systems such as absorption chillers, refrigeration applications, heat amplifiers, dehumidifiers, heat pumps for hot water, turbine inlet air cooling and other similar devices.

Conversion of Low Temperature Waste Heat into Power –The steam-Rankine cycle is the principle method used for producing electric power from high temperature fluid streams. For the conversion of low temperature heat into power, the steam-Rankine cycle may be a possibility, along with other known power cycles, such as the organic-Rankine cycle.

Small to Medium Air-Cooled Commercial Chillers – All existing commercial chillers, whether using waste heat, steam or natural gas, are water-cooled (i.e., they must be connected to cooling towers which evaporate water into the atmosphere to aid in cooling). This requirement generally limits the market to large commercial-sized units (150 tons or larger), because of the maintenance requirements for the cooling towers. Additionally, such units consume water for cooling, limiting their application in arid regions of the U.S. No suitable small-to-medium size (15 tons to 200 tons) air-cooled absorption chillers are commercially available for these U.S. climates. A small number of prototype air-cooled absorption chillers have been developed in Japan, but they use “hardware” technology that is not suited to the hotter temperatures experienced in most locations in the United States. Although developed to work with natural gas firing, these prototype air-cooled absorption chillers would also be suited to use waste heat as the fuel.

Recovery of Waste Heat in Cogeneration and Trigeneration Power Plants

In most cogeneration and trigeneration power and energy systems, the exhaust gas from the electric generation equipment is ducted to a heat exchanger to recover the thermal energy in the gas. These heat exchangers are air-to-water heat exchangers, where the exhaust gas flows over some form of tube and fin heat exchange surface and the heat from the exhaust gas is transferred to make hot water or steam. The hot water or steam is then used to provide hot water or steam heating and/or to operate thermally activated equipment, such as an absorption chiller for cooling or a desiccant dehumidifier for dehumidification.

Many of the waste heat recovery technologies used in building co/trigeneration systems require hot water, some at moderate pressures of 15 to 150 psig. In the cases where additional steam or pressurized hot water is needed, it may be necessary to provide supplemental heat to the exhaust gas with a duct burner.

In some applications air-to-air heat exchangers can be used. In other instances, if the emissions from the generation equipment are low enough, such as is with many of the micro turbine technologies, the hot exhaust gases can be mixed with make-up air and vented directly into the heating system for building heating.

In the majority of installations, a flapper damper or "diverter" is employed to vary flow across the heat transfer surfaces of the heat exchanger to maintain a specific design temperature of the hot water or steam generation rate.

In some co/trigeneration designs, the exhaust gases can be used to activate a thermal wheel or a desiccant dehumidifier. Thermal wheels use the exhaust gas to heat a wheel with a medium that absorbs the heat and then transfers the heat when the wheel is rotated into the incoming airflow.

A professional engineer should be involved in designing and sizing of the waste heat recovery section. For a proper and economical operation, the design of the heat recovery section involves consideration of many related factors, such as the thermal capacity of the exhaust gases, the exhaust flow rate, the sizing and type of heat exchanger, and the desired parameters over a various range of operating conditions of the co/trigeneration system — all of which need to be considered for proper and economical operation.
